27
Specification
General
Power supply:
12 V DC
Maximum power output: 50 W x 4 channels
Compatible formats: DVD/SVCD/VCD/HDCD/MP3/WMA/CDDA/Picture-CD/JPEG/ MPEG4 (DivX)
Supported disc types: DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW/USB/SD/MMC card
Dimensions (L x W x H): 165 x 178 x 50 mm
ESP function: 40 sec. for Audio CD, 120 sec. for MP3
TFT display
Screen size:
3.5” TFT
Resolution: 480 x 272
Aspect ratio: 4:3
Contrast ratio: 300:1
Brightness: 300 cd/m 2
View angle: V: 120 0 , H: 120 0
FM Stereo Radio
Frequency range:
65.0 – 74.0/87.5 – 108.0 MHz
Usable sensitivity: 15 dB
Preset memory stations: 18
AM section
Frequency range:
522 kHz - 1620 kHz
Preset memory stations: 12
Audio specification
Frequency response:
20 Hz - 20 KHz
S/N ratio: 85 dB
Separation 80 dB
Line out
Output:
4 channel RCA line-out (2V)
Specifications are subject to change without notice. Dimensions are approximate.
