PS Engineering
PMA6000 Series Audio Selector Panel and Intercom System
Installation Manual
200-066-0100 Page 1-1 Rev. 1, March 2005
Section I
GENERAL INFORMATION
1.1 INTRODUCTION
The PMA6000 family of Audio Selector Panels are revolutionary products. Never before has there been so
much capability and utility in such a compact package. These units are designed for ease of use and instal-
lation, as well as to facilitate cockpit resource management and improve passenger entertainment.
Before installing and/or using this product, please read this manual completely. This will ensure that you
will take full advantage of all the advanced features.
1.2 SCOPE
This manual provides detailed installation and operation instructions for the PS Engineering PMA6000-
series of Audio Selector Panel/Intercom Systems. This includes the following units:
Model Description Part Number
PMA6000 Audio Selector Panel 6000
PMA6000M Audio Selector Panel with Marker Receiver 6000M
PMA6000C Audio Panel with Com 3 6000C
PMA6000M-C Audio Panel w/MKR and Com 3 6000MC
-IRS Digital Recorder added to any PMA6000 -IRS
Option 2 No silver trim around the bezel Opt. 2
Where the functions are identical to all units, it will be referred to herein as a PMA6000. Otherwise, the
applicable units will be specified.
1.3 EQUIPMENT DESCRIPTION
The PMA6000-series is a state of the art audio isolation amplifier and audio selector that contains a voice
activated (VOX) intercom system. It can switch up to three transceivers (Com 1, Com 2 and TEL) and six
receivers (Nav 1, Nav 2, ADF, DME, MKR and AUX). In addition, there are two unswitched inputs, for
telephone ringer and altimeter warning. Push buttons select the receiver audio source provided to the head-
phones. A SPR button allows the user to listen to the receiver(s) selected on the cabin speaker. Except for
the unswitched inputs, all speaker audio is muted during transmit. A rotary switch selects one of the three
transceivers for the pilot and copilot position in transmit. In "Split Mode" the PMA6000 has the ability to
allow the pilot and copilot to operate different transmitters independently and simultaneously.
A fail-safe mode connects the pilot headphone and microphone to COM 1 if power is removed for any
reason, or if the Mic Selector switch is turned to the Off position.
A six-station voice activated (VOX) intercom is included in the PMA6000. pilot isolate and crew modes,
two mono music inputs with "Soft Mute," and a 2-color Light Emitting Diode for power and transmit indi-
cations. Intercom control is through front panel mounted knobs. Monaural units have dual concentric
knobs that control pilot volume and intercom squelch, and copilot/passenger volume and squelch. In the
stereo versions, there is a single volume and squelch control for all on board.
An optional 3-light Marker Beacon receiver is integral to the PMA6000M and PMA6000MC. This pro-
vides the necessary Marker Beacon light and audio indications necessary for an Instrument Landing Sys-
tem (ILS) approach.
