OWNER’S MANUAL
In extremely cold temperatures, the movement of the picture may be slow
and the picture may be dark, but this is not a malfunction. The set will work
normally once the temperature increases.
Small black and shiny dots inside the liquid crystal panel are normal for liquid
crystal product.
DESCRIPTION
The OHM642 is a TFT active matrix color LCD monitor that delivers a striking pic-
ture and superior image resolution. The OHM642 can be used to enjoy video
images with the Clarion video sources, even if no TV tuner is connected.
PACKAGE CONTENTS
6.4" monitor
5m long cable with 5 male connectors (A/V, Power/Ground, 3.5m IR)
Mounting Gasket
Mounting Bracket
Hardware
Owner's Manual
Warranty Card
BUTTON AND CONNECTOR LOCATIONS
5
1
3
2
6
4
7
1 Dome Light Switch
2 Monitor Release Button
3 Picture Select Up
4 Picture Select Down
5 IR Sensor
6 Dome Light Connector
7 8 Pin DIN Pigtail
