Rotary ironer RI800-16 Technical data for customer service 04/2005
TECHNICAL INFORMATION
Standards EN60335-2-44
EN55014-1
EN55014-2
EN61000-3-2
EN61000-3-3
Characteristics VDE-GS
VDE-EMC
Electrical connection 2780 Watt 220-240V 50 Hz 16 A
Dimensions Total height Total depth Total length
Working position ca 1020 mm ca 390 mm ca 980 mm
Folded ca 1060 mm ca 390 mm ca 590 mm
Weigth ca 46 Kg
Height (up to the lower part of
the base plate) ca 640 mm
Roller Length ca 855 mm
Roller Diameter ca 160 mm
Roller Pressure ca 17.5kg + 0.5kg
per mm laundry
thickness
Rotation Min 8 – max 15
r/pm
Distance between 35 - 40 mm
Ironing plate and roller
(swung away)
Quantity of thermostats 2 pcs
Heating element 1 x 2580 W
Motor load 150 W / 130 W
Transmission 1 : 422 / 1 : 85
On/Off switch (rocker switch) 0 - 1 with
red pilot light
