DLFE305
FREEZERS
A Division of National Refrigeration & A/C Products, Inc.
539 Dunksferry Road Bensalem, PA 19020
(800) 523-7138 Fax: (215) 244-9579
www.continentalrefrigerator.com
DL1FE-SS
DL1FX-SS
DL2FE-SS
DL3FE-SS
One Section
One Section-Extra Wide
Two Section
Three Section
CHARACTERISTICS
Reach-In Pass-Thru Reach-In
Pass-Thru
Reach-In
Pass-Thru
Reach-In
Pass-Thru
DIMENSIONAL DATA
Net Capacity (cu.ft.)
22
22
32
32
52
52
75
75
Width, Overall (in.)
28
1
/
2
28
1
/
2
36
1
/
4
36
1
/
4
57
57
85
1
/
2
85
1
/
2
Depth, Overall (Incl. Hdls.) (in.)
35
1
/
2
39
35
1
/
2
39
35
1
/
2
39
35
1
/
2
39
Depth (Less Door(s)) (in.)
32
32
32
32
32
32
32
32
Depth (Door(s) Open 90°) (in.)
58
84
66
100
58
84
58
84
Clear Door Width (in.)
21
7
/
8
21
7
/
8
29
5
/
8
29
5
/
8
21
7
/
8
21
7
/
8
21
7
/
8
21
7
/
8
Clear Full-Door Height (in.)
58
5
/
8
58
5
/
8
58
5
/
8
58
5
/
8
58
5
/
8
58
5
/
8
58
5
/
8
58
5
/
8
Clear Half-Door Height (in.)
27
1
/
2
27
1
/
2
27
1
/
2
27
1
/
2
27
1
/
2
27
1
/
2
27
1
/
2
27
1
/
2
Height, Overall (Incl. 6" Legs) (in.)
83
1
/
4
83
1
/
4
86
3
/
4
86
3
/
4
86
3
/
4
87
1
/
4
87
1
/
4
87
1
/
4
No. of Full Door(s)
1
2
1
2
2
4
3
6
No. of Half Door(s)
2
4
2
4
4
8
6
12
No. of Shelves
3
3
3
3
6
6
9
9
Shelf Area (sq. ft.)
20.4
20.4
24.4
24.4
40.8
40.8
61.2
61.2
Tray Slide Capacity (Half)
11 ea.
11 ea.
11 ea.
11 ea.
11 ea.
11 ea.
11 ea.
11 ea.
Tray Slide Capacity (Full)
24 ea.
24 ea.
24 ea.
24 ea.
24 ea.
24 ea.
24 ea.
24 ea.
REFRIGERATION DATA
Condensing Unit Size (H.P.)
1
/
3
1
/
3
1
/
2
1
/
2
1
/
2
3
/
4
3
/
4
1
Capacity (BTU/Hr)*
1590
1590
1840
1840
2470
3575
3575
4325
ELECTRICAL DATA
Cabinet Specifications
115/60/1
115/60/1
115/60/1
115/60/1
115/60/1
115/208-230/60/1
115/208-230/60/1
115/208-230/60/1
Feed Wires (Incl. Ground)
3
3
3
3
3
4
4
4
Condensing Unit Specs.
115/60/1
115/60/1
115/60/1
115/60/1
115/60/1
208-230/60/1
208-230/60/1
208-230/60/1
Total Amperes
7.6
8.0
12.5
12.8
12.8
9.3
9.3
12.1
Cabinet Amperes
1.6
1.9
1.8
2.1
1.9
2.9
2.9
3.9
Defrost Amperes
4.3
4.3
9.6
9.6
9.6
9.6
9.6
9.6
Power Supply Cord
yes
yes
yes
yes
yes
no
no
no
SHIPPING DATA
Height – crated (in.)
85
1
/
2
85
1
/
2
85
1
/
2
85
1
/
2
85
1
/
2
85
1
/
2
85
1
/
2
85
1
/
2
Width – crated (in.)
31
5
/
8
31
5
/
8
42
42
64
64
90
90
Depth – crated (in.)
42
42
42
42
42
42
42
42
Volume – crated (cu. ft.)
63
63
87
87
129
129
181
181
Weight Std – crated (lbs.)
355
385
455
460
610
720
865
960
Weight SS – crated (lbs.)
415
445
515
520
690
800
985
1075
Weight Std – uncrated (lbs.)
255
285
355
360
440
550
655
750
Weight SS – uncrated (lbs.)
315
345
415
420
520
630
770
865
*Rating @ -15°F Evaporator, 90° Ambient
Note: All specifications subject to change without notice.
Note: If the cabinet is located directly against wall and/or under low ceiling,
a minimum clearance of 2" is required.
Cabinet upper side panels and refrigeration plug system can be easily removed
and reinstalled at installation site where space limitations are confining.
83
1
/
4
"
28
1
/
2
"
6" ADJUSTABLE LEGS
32"
34"
35
1
/
2
"
6" ADJUSTABLE LEGS
86
3
/
4
"
57"
87
1
/
4
"
85
1
/
2
"
6" ADJUSTABLE LEGS
DL1FE-SS
FRONT VIEW
SIDE VIEW
DL2FE-SS
FRONT VIEW
DL3FE-SS
FRONT VIEW
86
3
/
4
"
36
1
/
4
"
DL1FX-SS
FRONT VIEW
6" ADJUSTABLE LEGS
