Every Two Months: Razor
Heads
pQ OQl m« UP lhe_cultefs and combs
adversely affected for several weeks
before ootimal shaving performaftce
isnestored.
D
Turn razor OFF.
B Press the razor head release
button and remove the Razor
Head Assembly from the
razor housing (fig. 8).
D Press the two sides of the
S'Shaped spring together and
remove the retaining frame
(fig-II).
□ Slide and remove one cutter
and comb out of the retaining
frame (fig. 12).
B Separate the cutter from the
comb.
□ Only brush the cutter in an
upward motion (fig. 13).
□ Brush the slots of the comb in
a circular motion (fig. 14) with
the supplied brush.
For opt'nxjm pcit'orTTianco.
cuners and combs shootd be cleaned
in a decreasing I kiuk J fe.?. akoholi
and lubricated with one dfT>D of
mineral oil in the center of the head
ffig, ISV This helps prevent wear of
the shaving heads.
Q Replace each cutter into the
comb and slide into the
retaining frame (8g. 16).
□ Press the retaining frame into
the Razor Head Assembly until
it locks into place (fig. 17).
IE] Replace the Razor Head
Assembly back on the razor.
This razor has no other user-
serviceable, oarts^ For assistancecall.
I•8QQ.243•ЗQ5Q.
