Page 26
25
♦
Front Panel
The front panel displays the activity of the SmartSwitch™
Router 250.
LED States
INDICATOR
DESCRIPTION
PWR
Green:
Power is applied
Off:
Power is not applied
TEST
Amber:
Running router Power-On-Self Test (POST)
Green:
Router POST test was successful
Off:
Router is non operational
LINK
Amber:
Establishing ADSL modem link
Green:
ADSL modem link succeeded
Off:
ADSL link is non operational
WAN
Green flashing:
Transmit or receive on WAN only
Off:
No WAN traffic
LANT
Green flashing:
LAN transmit traffic indication
Off:
No LAN transmit traffic
LANR
Green flashing:
LAN receive traffic indication
Off:
No LAN receive traffic
