RMD AXIAL EXHAUST FAN
Continental Fan Manufacturing Inc.
203 Eggert Road
Buffalo, New York 14215
Tel: (800) 779 4021 Fax: (716) 842 0611
Aeroflo Inc.
12-205 Matheson Blvd. East
Mississauga, Ontario L4Z 3E3
Tel: (905) 890 6192 Fax: (905) 890 6193
USA
www.continentalfan.com
Canada
www.aeroflo.com
IRIS DAMPERS
BATHROOM FANS
PANEL FANS
IN-LINE FANS
RMD-0807
MODEL
HT
W
B
C
D
E
RO
WT
(LBS)
DAMPER
SQUARE
MANUFACTURE
CODE
RMD-10
9.8
18.3
2
19
17.5
12
13
24
12
DDAR10
RMD-12
10.8
20.3
2
19
17.5
12
13
32
12
DDAR12
RMD-14
12.6
27.3
2
21
19.5
12
16
45
15
DDAR14
RMD-18
14.4
33.6
2
26
24.5
12
20
67
19
DDAR18
*DO NOT USE FOR CONSTRUCTION
CONSULT FACTORY FOR CERTIFIED PRINTS
DIMENSIONS IN INCHES*
F
FE
EA
AT
TU
UR
RE
ES
S &
& B
BE
EN
NE
EF
FIIT
TS
S
•
Axial impellers constructed with die formed blades riveted to a steel hub
•
Suitable for ROOF or WALL mounting
•
Spun aluminum housing for weather resistant durability
•
Wire conduit provides a clear channel for electrical connections
•
Bird screen
•
Totally enclosed, permanently lubricated, ball bearing motor
•
Disconnect switch
•
110 F max. temperature rating
•
Available in 115V 1 phase
A
AC
CC
CE
ES
SS
SO
OR
RIIE
ES
S // O
OP
PT
TIIO
ON
NS
S
•
Gravity damper
•
Motorized damper
•
Wall mount sleeve
•
Roof curb
MODEL
RPM
MTR
HP
0” S.P.
CFM
0.125” S.P.
CFM
0.25” S.P.
CFM
0.375” S.P.
CFM
0.50” S.P.
CFM
0.625” S.P.
CFM
0.75” S.P.
CFM
0.875” S.P.
CFM
RMD-10
1500
.03
500
339
267
173
-
-
-
-
RMD-12
1500
.10
830
710
620
522
436
357
270
-
RMD-14
1100
.17
1160
899
786
646
521
384
236
-
RMD-18
1100
.33
2400
2034
1628
1491
1293
1084
881
662
PERFORMANCE
CURB (OPTIONAL)
3" FLANGE
20 GAUGE
STEEL
CONSTRUCTION
E
D
D
RO
RO ROOF OPENING
DIMENSIONS
C
S
B
HT
W
R
RM
MD
D A
AX
XIIA
AL
L E
EX
XH
HA
AU
US
ST
T F
FA
AN
N
