Fuses
Usage
ELC EXH
Electronic Level Control,
Exhaust Solenoid (Option)
DDM
Driver Door Module, Front Door
SubWoofers (Option)
TV/VICS/SCM
Infotainment (Export Only),
Supervisory Control Module (Option)
REAR
HTD/SEATS
Rear Heated Seats
SPARE
Spare
SPARE
Spare
IGN3
Front Passenger Heated Seat,
Auto Shifter, Occupant Protection,
Electronic Tension Reducer for
Seatbelt
REAR SHLF
SPKR
Rear Shelf Speaker (Option)
MSM
Memory Seat Module Lumbar
TRUNK
RELSE SW
Trunk Release, Valet Lockout
Switch
BCK/UP LAMP
Reverse Lamps, Rear Parking Aid,
Inside Rearview Mirrors
AIR BAG/BATT Airbag
POS LAMPS
Rear Taillamps
ELC CMPRSR
Automatic Level Control (Option)
Relays
Usage
INCLR PUMP
Inner Cooler Pump (Option)
ELC CMPRSR
Electronic Level Control,
Compressor (Option)
LT POS
Left Rear Taillamp, Position
Lamps (Option)
RT POS
Right Rear Taillamp, Position
Lamps (Option)
RUN
Ignition 3
STDBY LAMP
Rear Taillamps, Position
Lamps (Option)
TRUNK RELSE Trunk Release Motor
BCK/UP LAMP
Reverse Lamps, Rear Parking Aid,
Inside Rearview Mirror
Circuit
Breakers
Usage
PWR SEATS
Power Seats
Diodes
Usage
SPARE
Spare
Joint
Connector
Usage
J/C
Splice Pack (Green)
5-131
