H ooking
U
p Y our
TV (A ntenna /C able C onnections ) (C ont ’ d )
VCR
TO
TV
—fBEGINl-
B asic C onnection
J ^he basic Antenna /
Cable to VCR to TV
connection is shown here.
For more information on
other hookups (with Cable
Converter Boxes or
Descrambler Boxes), refer
to your VCR or Cable
Converter Box Owner's
Manual.
■4> Connect your Antenna
or Cable signal to the IN
FROM ANT(enna) plug on
the
VCR.
Connect the OUT TO TV
plug on the VCR to the
ANT(enna) IN plug on the
TV (using the connecting
cable supplied with the
VCR).
Refer to the VCR Owner’s
Manual for other possible con
nections and for TVA^CR oper­
ating details.
Outdoor VHF/UHF
Antenna
300 to 75 fì! Adaptor
Round Cable
75¡Q Supplied with
VCR
Back of TV
r ® C able
TV
C able /C onverter
y bur Cable TV signal
may be a single (75(2)
cable or it may use a
Cable Converter Box. In
either case, the connection
to the TV is easy.
■(BEGIN)-------------------------------
r<3>
If your Cable TV sig­
nal is a single round cable (75
O) then you're ready to connect
it to the TV.
If you have a Cable
Converter Box:
Connect the Cable TV signal to
the Cable Signal IN plug on the
Cable Converter Box.
Note to the Cable TV System Installer: This reminder is provided to call the
Cable TV system installer’s attention to Article 820-40 of the National Electrical
Code, which provides guidelines for proper grounding - in particular, specifying
that the cable ground shall be connected to the grounding system of the building,
as close to the point of cable entry as possible.
Connect the Cable TV
cable to the ANT(enna) IN
plug on the TV.
If you have a Cable Converter
Box:
Connect the OUT plug of the
Cable Converter Box to the
ANT(enna) IN plug on the TV
using a round cable (750, coaxi­
al).
NOTE: The connecting cable for
the Cable Converter Box may be
supplied by the Cable TV company.
Back of TV
Remember,
set the TV for the
type signal you've
connected (see
Automatic Channel
Setup, page 5).
To select only the
channels on your
Cable system, see
Automatic Channel
Setup, page 5. If
you use a Cable
Converter Box, set
the TV to the same
channel as the CH
3/4 switch on the
rear of the Cable
Converter Box.
Round Cable 750
-3-
