Installation Instructions CTA-2536
3
CONTENTS
PARTS ..............................................................................2
INSPECT THE UNIT BEFORE INSTALLING ..............3
TOOLS REQUIRED FOR INSTALLATION..................3
INSTRUCTIONS..............................................................4
Determine a Suitable Mounting Location .....................4
Installing the Wall Plate ................................................4
Attaching Wall Arm to Wall Plate ................................5
Attaching Front Cover...................................................5
Connecting NPT Pipe or Nipple to Wall Arm...............5
INSPECT THE UNIT BEFORE
INSTALLING
Unpack the carton. Carefully inspect the parts for
shipping damage. Verify contents listed in Table 1.
If you are missing any of the listed parts, contact
Customer Service at: 1-800/582-6480.300.
Table 1. Shipping Contents
ITEM DESCRIPTION QTY
10 Wall Plate 1
20 5/16 X 2.5” Lag Bolt 6
30 5/16 Flat Washer 6
40 M8 Flat Washer 6
50 M8 Lock Washer 6
60 M8 X 16mm Button Head Cap Screw 6
70 M5 Allen Key 1
TOOLS REQUIRED FOR
INSTALLATION
The tools required for installation are as follows:
• Electric drill and bit set
• Stud sensor (mechanical or electronic)
• ½” box-end wrench or ratchet with ½” socket
• 13mm box-end wrench or ratchet with 13mm socket
• Level
NOTE: Other tools may be required depending on
your method of installation.
