SPECIFICATIONS
16
CONTROL
...........................................................................................................................................................................
RS-232 Interface
Connection DB-9F, straight-wired
Pinout (Statement DI side) Pin 2: Tx, Pin 3: Rx, Pin 5: Ground
Baud Rate 57600
Configuration 8 data bits, 1 stop bit, no parity bits,
flow control (RTS, CTS, NONE)
...........................................................................................................................................................................
Trigger Outputs
Polarity 3.5 mm mono (tip positive), sleeve negative
Maximum Current at 12 VDC 150 mA (Triggers 1,2), 200 mA (Trigger 3)
Sequential Delay 100 ms
...........................................................................................................................................................................
POWER REQUIREMENTS
...........................................................................................................................................................................
Power Requirements 117VAC or 234VAC 50-60Hz
...........................................................................................................................................................................
Power Consumption Maximum 50 W
...........................................................................................................................................................................
