3

UVDR Series Unvented Gas Fireplaces

20007469

C

F

J

G

E

K

Gas Line

Access

Rough Opening Width C

Rough

Opening

Height

Rough

Opening

Depth

P

N

M

P

L

H

E

D

B

A

6���"

78984

ADF36/42C

SPECS

2/04

Fireplace Dimensions

Fig. 1a UVDR36/42C specifications and framing dimensions.

1/2” Clearance to

Combustibles not Required

at this Point

1/2” Clear-

ance to

Combustibles

not Required

at this Point

UVDR36C

UVDR42C

A

36”

42”

B

21⁷⁄₈”

21⁷⁄₈”

C

39”

45”

D

7”

8”

E

35”

39”

F

38¹⁄₄”

42¹⁄₄”

G

9”

10¹⁄₂”

H

21”

22”

J

8⁵⁄₈”

9³⁄₄”

K

22”

32”

L

21”

22”

M

65”

76¹⁄₄”

N

32¹⁄₂”

38¹⁄₈”

P

46”

54”
