Specifications
Operating Steam Pressure
4-Coil .................................................. 100 PSIG Max.
6-Coil .................................................. 100 PSIG Max.
Boiler HP (with normal load)
4-Coil .................................................. 7.87
6-Coil .................................................. 9.50
Heat Capacity
4-Coil
6-Coil
Steam Coils
4-Coil .................................................. (2) 40 1/2” L x 6” W x 10 1/4” H (102.87 cm
x 15.24 cm x 26.04 cm)
6-Coil .................................................. (2) 40 1/2” L x 15 3/4” H x 6” W
(2) 102.87 cm x 15.24 cm x 40.01 cm)
Traps for Steam Heating Coils
4-Coil .................................................. 3/4” (1.91 cm) (2)
6-Coil .................................................. 3/4” (1.91 cm) (2)
Steam Supply Line
4-Coil .................................................. 3/4” (1.91 cm)
6-Coil .................................................. 3/4” (1.91 cm)
Steam Return Line
4-Coil .................................................. 3/4” (1.91 cm)
6-Coil .................................................. 3/4” (1.91 cm)
Drying Time .......................................... 110 lbs. (49.9 kg) dry weight
(Approx. - testing in lab.) ...................... Indian Head cloth
4-Coil .................................................... High Pressure (100 PSIG Max.) 70% water
retention - 38 min.
6-Coil .................................................... High Pressure (100 PSIG Max.) 70% water
retention - 31 min.
(Low Pressure requires
longer drying time)
4-Coil .................................................. 50% water retention - 28 min.
6-Coil .................................................. 50% water retention - 24 min.
Drying Time
(Dry Weight)
60 KW .................................................. 110 lbs. (49.9 kg) Indian Head cloth
80 KW .................................................. 110 lbs. (49.9 kg) Indian Head cloth
(Approx. - testing in lab.)
60 KW .................................................. 70% water retention - 40 min. 50% water
retention - 30 min.
80 KW .................................................. 70% water retention - 31 min. 50% water
retention - 23 min.
STEAM HEATED DRYERS
ONLY
ELECTRIC LAUNDRY DRYER
(see Electric Bonnet Sheet)
