Audio Expander Crestron Adagio™ AAE
Specifications
Specifications for the Adagio AAE Audio Expander are listed in the following table.
Adagio AAE Audio Expander Specifications
SPECIFICATION DETAILS
Audio
Controls Volume, Balance, Bass, Treble, Loudness,
Mute, On/Off, Room On/Off, Source Select,
Mono/Stereo and Input Compensation
Volume Gain -80 to +20dB in 1dB steps
Mute -100dB (electronic),
-120dB (amp output relay)
Input Compensation ±10dB
Bass Gain Range ±12dB @ 100Hz (2dB increments)
Treble Gain Range ±12dB @ 10kHz (2dB increments)
Frequency Response 20Hz to 20kHz ±0.75dB
S/N Ratio 100dB, 20 Hz to 20kHz A-weighted
THD+N 0.05%, 20Hz to 20kHz
Stereo Separation >75dB
Power
Internal (consumption) 7 Amps, 120 Volts AC @ 60Hz (AAE)
3.5 Amps, 230 Volts AC @ 50Hz (AAEI)
Available Cresnet Power
(output)
Heat Dissipation
8-ohm impedance
4-ohm impedance
50 Watts (2.08 Amps @ 24 Volts DC)
700 BTU/hr
800 BTU/hr
Default NET ID 31
Operating Environment 41° to 104°F (5° to 40°C)
10% to 90% RH (non-condensing)
Enclosure Black metal with molded ABS/PC front
panel; freestanding
Dimensions Height: 5.64 in (14.33 cm)
Width: 17.16 in (43.59 cm)
Depth: 18.08 in (45.92 cm)
Weight: 36.6 lbs (16.2 kg)
NOTE: Cable connections can extend the overall depth of the AAE by
approximately two to three inches.
