T4.8
5
INSTALLATION
1.Wall bracket
1.Flying
Optional Installation Accessories
The T4.8 cabinet has 3 flying points, plus a stand mount
adaptor to ensure fast and easy installation. To install
stacked speakers there are an optional coupling brackets.
INSTALLATION
1.Wall bracket
Installation Options
Extension mount
2. Speaker coupling
Warning: Always ensure the mounting accessories
safety factor is not less than 5:1 or that it meets the
local standards.
T series full range speaker line array column
2.Speaker coupling brackets
Ceiling mount Wall mount
