DISPLAY KEY
DISPLAY MODE FUNCTION
ADDR DMX ADDRESS
SETTING A001 - A512
CHND CHANNEL MODE 9 CH / 12 CH
SLND SLAVE MODE MAST, SL1, SL2
SOUN SOUND ACTIVE MODE SOUND ON/OFF
SENE SOUND SENSITIVITY 0-100
BLND BLACK OUT MODE LED MODE, YES - NO
DISP DISPLAY INVERSION INVERTS MENU
DISPLAY
TEST TEST MODE SELF TEST
HOUR LIGHT TIME FIXTURE HOURS,0-9999
DMX CONTROL SETTINGS
9 CHANNEL MODE
CHANNEL FUNCTION
CH. 1 000-007 BLACK OUT
008-200 DIMMER
201-247 STROBE
248-255 FULL BRIGHT
CH. 2 001-255 RGBW COLOR MIXING
CH. 3 000-255 X-AXIS MOTOR
CH. 4 000-255 Y-AXIS MOTOR
CH. 5 000-007 BLACK OUT
008-255 COLOR MACRO
CH. 6 000-255 COLOR MACRO SPEED
CH. 7 000-007 BLACK OUT
008-255 MOTOR RUN
CH. 8 000-255 MOTOR RUN SPEED
CH. 9 000-127 SOUND OFF
128-255 SOUND ON
30 CHANNEL MODE
CHANNEL FUNCTION
CH. 1,6,11,16,21,26 000-255 PAN MOVEMENT 0- 180˚
CH. 12,7,12,17,22,27 000-255 TILT MOVEMENT 0- 70˚
CH. 3,8,13,18,23,28 000-007 BLACKOUT
008-024 RED
025-041 GREEN
042-057 BLUE
058-074 WHITE
075-090 RED & GREEN
091-107 RED & BLUE
108-123 RED & WHITE
124-140 GREEN & BLUE
141-156 GREEN & WHITE
157-173 BLUE & WHITE
174-189 RED, GREEN & BLUE
190-206 RED, GREEN & WHITE
207-222 RED, BLUE & WHITE
223-239 GREEN, BLUE & WHITE
240-255 RED, GREE, BLUE &
WHITE
CH. 4,9,14,19,24,29 000-255 DIMMER 0 – 100%
CH.5,10,15,20,25,30 000-008 OPEN
009-255 STROBE EFFECT SLOW
TO FAST
