Page 9
BASIC ENGINE PARTS
Drive Hub
Propeller Washer
Propeller Nut
Crankcase
Lock Nut
Crankshaft
Cylinder Head
Carburettor
Type 7D-RN
Glow plug
Cover Plate
Fuel inlet
Silicone tubing
Remote Needle
Fuel outlet
INSTALLATION OF THE ENGINE
Rigid hardwood
(e.g. maple)
At least
12mm(1/2")
At least
12mm(1/2")
O.S. radial motor mount
(Available as an optional extra part. See parts list)
A typical method of beam
mounting is shown below, left.
Installation in the model
For 108FSR(BX-1) (Code No. 71907000)
8
