Page 15

26
ENGINE EXPLODED VIEW
Type of screw
C...Cap Screw M...Oval Fillister-Head Screw
F...Flat Head Screw N...Round Head Screw S...Set Screw
C.M3x15
C.M3x8
C.M2.6x20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
27
The specifications are subject to alteration for improvement without notice.
ENGINE PARTS LIST
Screw Set
Cover Plate
Gasket Set
Crankshaft
Crankshaft Ball Bearing(Rear)
Crankcase
Crankshaft Ball Bearing(Front)
Thrust Washer
Propeller Nut
Carburetor Retainer Assembly
Carburetor Complete 60K
Connecting Rod
Piston Pin
Cylinder Liner
Heatsink Head
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Code No.
Description
Piston Ring
Piston
Piston Pin Retainer (2pcs.)
Glow Plug No.8
27004300
27003100
27003400
27003200
27006000
27917000
27005000
27081000
45010002
46120000
26731002
27981710
27001000
27930000
27002000
27014000
27007000
25613000
71608001
27708200
41621100
Needle Adjusting Screw (5pcs.)
Woodruff Key
