O.S. Engines 21XM - Manual (Page 19)

2 4981 405
2 6381 501
2 5381 203
2 6781 309
2 4881 824
2 6781 506
2 5382 100
2 5381 220
No.
1
1-1
2
3
3-1
4
5
6
Throttle Lever Assembly
Set-screw
Carburettor Rotor
Mixture Control Valve
'' O '' Ring (2pcs.)
Rotor Spring
Carburettor Body
Rotor Guide Screw
Code No. Description
Fuel Inlet
Needle Valve Assembly
Needle
'' O '' Ring (2pcs.)
Set-screw
Needle Valve Holder Assembly
Ratchet Spring
Carburettor Rubber Gasket
Code No. Description
2 2681 953
2 7881 900
2 4981 959
2 4981 837
2 6381 501
2 7381 940
2 6711 305
2 9015 019
No.
7
8
8-1
8-2
8-3
8-4
8-5
9
The specifications are subject to alteration for improvement without notice.
CARBURETTOR EXPLODED VIEW & PARTS LIST
1-1
1
2
3
3-1
4
5
6
7
8
8-1
8-2
8-3
8-4
8-5 9
S.3X3
S.3X3
18
