O.S. Engines 18CV-RX - Manual (Page 14)

26
11G CARBURETOR EXPLODED VIEW
C. M 3 . 5 x 8
1
1 - 1
1 - 2
2
2 - 1
2 - 2
3
4
5
6
7
8
9
Type of screw
C...Cap Screw M...Oval Fillister-Head Screw
F...Flat Head Screw N...Round Head Screw S...Set Screw
27
1
1-1
1-2
2
2-1
2-2
3
4
5
6
7
8
9
21285600
46066319
22781800
21285901
27881820
21881950
23818500
21883100
21483200
21483600
21881320
23818420
22615000
11G CARBURETOR PARTS LIST
The specifications are subject to alteration for improvement without notice.
Description Code No. No.
Mixture Control Valve Assembly
"O" Ring(L) (2pcs.)
"O" Ring(S) (2pcs.)
Needle Valve Assembly
"O" Ring (2pcs.)
No.14 Universal Nipple Assembly
Throttle Stop Screw
Carburetor Body
Slide Valve
Metering Needle Assembly
Dust Cover
Ball Link No.4
Carburetor Rubber Gasket
