CAR AUDIO CD/MP3 PLAYER WITH DIGITAL
RADIO RECEIVER
Model VT - 3606
OPERATING CONTROLS (FIG. A)
1. Power ON/OFF ( )
2. Settings menu button (“SEL”): Bass / Treble /
Channel Balance / Fader / Traffic Information
Reception / Alternative Frequencies / Changing
Stations / Audio Processor / Tone
Compensation / Shock protection mode /
Audible signal / Scan / Radio operating mode /
Radio Settings / default volume level setting.
3. Increase / Decrease volume knob (“VOL
UP/DOWN”)
4. Radio station preset buttons (1,2,3,4,5,6)
5. “AF/REG” function – to scan for radio stations
on different frequencies
6. “TA” function – to search for traffic information
7. “PTY” function – to choose preferred program
types
8. Display mode setting (“DISP”)
9. MODE select button
10.BAND select button
11.Automatic or manual radio station tuning (fre-
quency up (UP) : or frequency down (DOWN)
9) / CD Track/Search
12.Automatic radio station search (“AS/PS”)
13.Automatic band scanning (“SCN”)
14.Sound muting button (“MUTE”)
15.LCD screen
16.Button for remove front panel ( )
17.Disc slot
18.Disc eject button (“EJ”)
19.Button for pausing playback (“PAU”)
20.Introduction mode playback button (“INT”)
(Preliminary playback of all tracks)
21.Track repeat button (“RPT”)
22.Random playback button (“RDM”)
23,24. Quick jump + 10 tracks up/down. (For MP3
files)
INSTALLING THE UNIT IN YOUR AUTOMOBILE
(FIG. B)
1. The device
2. Guide rails
3. Front panel
4. Hex bolt
5. Lock-nut
6. Flat disc
7. Car body
8. Bracket
9. Securing screws
10.M5 hex bolts X 15
ISO JACKS (FIG. C)
Line audio out (RCA):
Gray: Red (right channel)
: White (left channel)
Plug A
1.
2.
3.
4. Yellow wire: Memory +12 V
5. Blue wire: Antenna power
6.
7. Red wire: +12 V (to ignition)
8. Black wire: Ground (-)
Note: Contact 7 of plug A should be connected
to the car’s ignition so that the deck is turned off
when the engine is not running and doesn’t
wear down the battery.
Plug B
1. Violet wire: Right rear speaker (+)
2. Violet wire with black stripe: Right rear speaker
(-)
3. Gray wire: Front right speaker (+)
4. Gray wire with black stripe: Front right speaker
(-)
5. White: Front left speaker (+)
6. White wire with black stripe: front left speaker (-)
7. Green wire: Left rear speaker (+)
8. Green wire with black stripe: Left rear speaker(-)
MAINTENANCE
Changing the fuse
If the fuse burns out, check the connection to
power and replace the fuse. If the fuse burns out
again after being replaced then there may be
and internal malfunction. If this happens, con-
sult with your nearest service center.
Warning
Use a fuse of the indicated current level for each
wire. Using fuses with high current levels can
lead to serious damage.
INSTALLATION
SAFETY MEASURES
• Carefully choose the installation location so that
the device will not impede the normal operation
of the automobile.
• Avoid installing the device in places where it may
be subjected to sources of high temperatures,
such as direct sunlight, hot air from the heater,
or where it can me damaged by dust, dirt or
excessive shock.
• For safe and reliable installation use only the
parts provided.
• Remove the front panel before installing the
device.
Setting the installation angle
The allowable degree of slant from the horizon-
tal position is no more than 20°.
