Product features:
Tracing network line (4 cores) directly when connected with switch
or router. (NF-801 don't).
The wire can be hunted directly in connection with Ethernet switch/
router /PC terminal of different models in startup.
the wire can also be hunted directly such as 5E, 6E, telephone
line, coaxial cable and other cables.
Test 5E, 6E directly, troubleshooting open, short, cross errors.
RJ45/RJ11/BNC and other ports are included and the complex
switch is not required.
Endurable high pressure and self-protection ability.
Earphone and backlight help you operate in dark.
9V battery for power supply and low-voltage hint function.
Specification:
8Vp-p
≤20mA
≤30mA
≥3km
0.083kg
0.096kg
187Ч46Ч27 mm
0.458kg
285Ч150Ч46 mm
146Ч57Ч30 mm
Specification
Wire tracker
DC, 9V battery
Item
Product name
Power supply
The max working current
Signal transmission format
Signal output electric status
Distance of signal transmission
Appearance dimension
Weight
Emitter
Receiver
Multi-frequency impulse
Emitter
Whole set
Emitter
Receiver
Receiver
Whole set
