NetWork
Cable Tester
1.wiremap
2.pair&length
3.coax/tel
4.setup
Product operation methods
Bott Screen:
Carry out self-checking at the same time (The dotted line dynamically
displays the course of self-checking from left to right):
Wait 5 seconds or push any arbitrary key to display main menu.
Main menu display:
Wiring diagram (WIREMAP) test function:
After entering the wiring diagram (WIREMAP), the tester shall
carry out wiring diagram (WIREMAP) test and displays as follows
----T e s t i n g ----
There are four functions to be chosen on main menu.
1. WireMap --- Wiring diagram measurement to check end-to-end
continuity of cables in M, L, R and locate errors.
2. Pair & Length ---Pair and measure length to know open,short,points,
verify cable length,open circuit distance.
3. Coax/Tel --- Coaxial cable and telephone line measurement to check
continuity and indicate open circuit and short circuit.
4. SETUP---Calibrate and set up the tester (Refer to description
hereinafter).
Note: Never put a charged telephone cable into Rj45 port for fear
of burnout to the testers.
12345678...
