3 temperature probe – NORAC UC4.5-BC-FT3 User Manual
Page 18
15
Figure 17: Roll Sensor Mounting (Viewed from the rear of sprayer)
6.3 Temperature Probe
Once the block is mounted, fasten the temperature probe from E03 to the NORAC valve
block using the included 3/8x1/2” bolt as illustrated in Figure 18.
Figure 18: NORAC Valve Block with Temperature Probe Installed
E03
E04
