6 roll sensor installation – NORAC UC4.5-BC-EU1 User Manual
Page 18
15
6 Roll Sensor Installation
Before installing the roll sensors, determine if the sprayer has a trapeze style, center pivot style
or high pendulum style boom. For installation on a trapeze style boom refer to Section 6.2.
For installation on a center pivot boom refer to Section 6.3. For installation on a high
pendulum boom refer to Section 6.4
Figure 14: Trapeze Style Boom
Figure 15: Center Pivot Boom
Trapeze
Links
Center
Pivot
