For Replacement Parts or Technical Assistance,
Call 1-800-543-6400
Please provide following information: Address any correspondence to:
- Model number Campbell Hausfeld
- Serial number (if any) Attn: Customer Service
- Part description and number as shown in parts list 100 Production Drive
Harrison, OH 45030 U.S.A.
Replacement Parts Manual NB003006
www.chpower.com
Ref.
No.
Description Part Number Qty
1 Bolt - M5 x 20 ✧ 6
2 Lock washer - M5 ✧ 4
3 Head cap ✛ 1
4 Seal ❑ 1
5 Compressed spring ◆ 1
6 O-ring ◆ ❑ 1
7 Head valve piston ◆ 1
8 O-ring ◆ ❑ 1
9 Gasket ❑ 1
10 O-ring ❑ 1
11 Collar ✛ 1
12 O-ring ❑ 1
13 O-ring ❑ 1
14 Cylinder ✛ 1
15 O-ring ◆ ❑ 1
16 O-ring ● ❑ 1
17 Driver piston ● 1
18 Driver pin ● 1
19 Bumper ❑ 1
20 Body ✛ 1
21 Nozzle ✛ 1
22 Upper valve body ✛ 1
23 O-ring ■ ❑ 1
24 Spring ■ 1
25 Trigger valve stem ✛ 1
26 O-ring ■ ❑ 1
27 O-ring ■ ❑ 1
28 Lower valve body ✛ 1
29 O-ring ■ ❑ 1
30 Spring ✛ 1
31 Step pin ▼ 3
32 Trigger ▼ 1
33 O-ring ■ ▼ ❑ 3
34 Trigger plate ▼ 1
35 Pin ▼ 1
36 WCE guide ✛ 1
37 Compressed spring ✛ 1
38 Pin ✛ 1
39 Work contact element (WCE) ✛ 1
40 Spacer ✛ 1
41 Quick release handle ✛ 1
42 Release lever ✛ 1
43 Upper nose ✛ 1
44 Roll pin ✧ 1
45 Bolt - M4 x 8 ✧ 4
Ref.
No.
Description Part Number Qty
46 Drive guide SV536500AV 1
47 Steel bar ✛ 1
48 Magazine ✛ 1
49 Magazine cover ✛ 1
50 Set screw ✛ 2
51 Magazine bracket ✛ 1
52 Bolt - M4 x 12 ✧ 2
53 Pusher ▲ 1
54 Pusher pin ▲ 2
55 Pusher spring ▲ 2
56 Bolt - M4 x 8 ✧ 2
57 Spring lever ✛ 1
58 Bolt - M4 x 16 ✧ 1
59 Leg hanger ✛ 1
60 Nut - M4 ✧ 1
61 O-ring ❑ 1
62 Inlet cap ✛ 1
63 Driver blade ● 1
64 Rubber seal ■ 1
65 Safety decal (not shown) ✛ 1
66 Magazine decal (not shown) ✛ 1
REPLACEMENT PARTS KITS
▲ Pusher assembly SKN04600AV
■ Trigger valve o-ring kit SKN04700AV
● Driver kit SKN04800AV
◆ Head valve assembly SKN04900AV
▼ Trigger assembly SKN05000AV
❑ Complete o-ring kit SKN05100AV
✧ Standard hardware item - available at your local
hardware store
✛ Not available
