- 24 -
REPLACEMENT PARTS LIST
D
ESCRIPTION
D232
1.
Log Set Complete
10000160
1a.
Log Ember Front
KR1
1b.
Log Front Left
KR2
1c.
Log Front Right
KR3
1d.
Log Rear
KR4
1e.
Log Top Left
KR5
1f.
Log Top Right
KR5
2.
Burner Lava Rock (Package)
57897
3a.
Burner with Tiles Nat.
57903
3b.
Burner with Tiles Prop.
57904
4.
Ceramic Tile (Single)
57803
5a.
Orifice Front Nat.
SEE RATING PLATE FOR ORIFICE SIZE
5b.
Orifice Front Prop.
SEE RATING PLATE FOR ORIFICE SIZE
6a.
Orifice Main Nat.
SEE RATING PLATE FOR ORIFICE SIZE
6b.
Orifice Main Prop.
SEE RATING PLATE FOR ORIFICE SIZE
7a.
Orifice Pilot SIT Nat.
54273
7b.
Orifice Pilot SIT Prop.
54272
8a.
Orifice Pilot PSE Nat.
10001822
8b.
Orifice Pilot PSE Prop.
10001823
9a.
Pilot Assembly SIT Nat.
10000674
9b.
Pilot Assembly SIT Prop.
10000675
10a.
Pilot Assembly PSE Nat.
10001741
10b.
Pilot Assembly PSE Prop.
10001742
11.
Pilot SIT-Top Convertible
10001295
12.
Pilot w/ignitor and cable PSE
10001824
13.
Pilot Tubing w/fittings
53211
14.
Manifold Tubing w/fittings
57318
15.
Thermocouple SIT
53373
16.
Thermocouple PSE
10001825
17.
Thermopile
51827
18.
Electrode Ignitor w/cable SIT
10001297
19.
Ignitor Piezo SIT
52464
20.
Ignitor Piezo Honeywell
20000062
21a.
Valve SIT 820 Nat.
52677
21b.
Valve SIT 820 Prop.
52678
22.
Extension Knob Hi/Lo SIT (RN/RP)
10000165
23
Extension Knob On/Off SIT (RN/RP)
10000166
24a.
Valve Honeywell Nat.
10001782
24b.
Valve Honeywell Prop.
10001759
25a.
Valve Eurosit 630 Nat.
53448
25b.
Valve Eurosit 630 Prop.
53446
26.
Fan with Bracket
54103
27.
Electrical Cord (6ft.)
51865
28.
Fan Temperature Sensor
51704
29.
Speed Control
51738
30.
Speed Control Knob
51882
31.
Glass with Gasket - Front
52035
32.
Glass with Gasket - Side
52032
33.
Gasket Glass
57316
36a.
Frame Window - Left Side
52145
36b.
Frame Window - Right Side
52860
37.
Frame Window - Front
57244
39.
Trim Frame Window (PB)
52027
41.
Top Louvre
52019
42.
Front Louvre Assembly
57908
43.
Access Door Assembly (with handle)
52030
44.
Latch
52057
45.
Remote Switch
53606
46.
Remote Wire Harness with Terminals
57265
