Quick Programming & Setup Guide
MCS 250
The intent of this guide is to assist the user in getting the dialer on line in the least amount of time. NOTE: As part of the final
assembly procedure the battery was temporarily disconnected thereby erasing all previously recorded voice messages. For
additional, and more complete information refer to the MCS-250 manual. After turning the dialer ON, follow the steps as
they are listed.
HALT Mode: User programming must be done while in HALT mode. Pressing the HALT key enters
the HALT mode. In HALT mode, the RUN light is red.
To Enter Telephone Numbers: ENTER, No.(1-8), Phone # up to 16 digits (DELAY for pauses), ENTER
READ, No.(1-8) - Makes a test call, HALT terminates it. When dialing a
number, the Off Hook light comes on.
To Enter Fault Messages: ENTER, MESSAGE, No.(0-7), ENTER = 4 sec. fault message -or-
ENTER, MESSAGE, No.(0-7), # =8 sec. fault message -or-
ENTER, MESSAGE, No.(0-7), * =4 sec. status message
Message 0 = System Identification
Message 1-4 = Fault Messages
Message 5 = AC Power
Message 6 = Message for when all Channels are normal
Message 7 = Message for Proper Acknowledgement
To Read A message: READ, MESSAGE, No.(0-7)
When Entering and Reading messages, the Message In Progress light will come on. Once a
message is recorded, it is read back to the user.
Fault Delay Program: ENTER, DELAY, No.(1-5), Set for 1...99 Seconds, (Each Blink = 1 Second), ENTER
READ, DELAY, No.(1-5) - Then Count the Number of Blinks
Normally Open/Closed: ENTER, MODE, No.(1-5), wait for Red or Green, ENTER.
Operational Parameters
Ring Count: ENTER, *, 01...99(Rings)
To test, have someone call the unit.
Tone/Pulse: ENTER, MODE, 0, (0 for pulse, 1 for tone)
To test, have it make a callout.
Message Reps: ENTER, #, 01...99(Message Reps)
To test, have it make a callout and count the repetitions.
Intercall Delay: ENTER, DELAY, 0, 01...99(Hours)
To test, create a fault, acknowledge it and then time the intercall delay period.
Delayed RUN:
DELAY, RUN, 01...99(Minutes)
This will wait in HALT mode for this time period then go into RUN mode.
RUN Mode: Enters RUN mode when the user presses the RUN key. In RUN mode, the RUN light is
green.
Acknowledged Calls: Accomplished by depressing the * key on the called telephone between message repeats.
The * key must be held down for at least 2 full seconds but not longer than 5 seconds.
The * key can be depressed at the dialer in order to acknowledge an alarm.
Call back acknowledgment can be accomplished by calling the dialer within 70 seconds
after having been called.
24
