CLIFFORD Model RSX1.5 - Manual (Page 12)

9 9
© 2005 Directed Electronics—all rights reserved
Icon
The transmit icon will be displayed while the remote control is
transmitting a command to the vehicle.
Icon
The receive icon will be displayed while the remote control is
receiving a page from the vehicle.
Icon
The signal icon will be displayed if a command is transmitted to
the vehicle but a command page is not received.
Icon
The locked status icon will be displayed when the system is locked.
Icon
The unlock status icon will be displayed when the system is
unlocked.
Icon
The disarm icon will flash when the system is unlocking the
doors.
Icon
The arm icon will flash when the system is locking the doors.
Icon
Not applicable.
SSttaan nd daarrd d IIcco on n CCo on nffiig gu urraattiio on nss
