LOCATION OF CONTROLS
Front Panel
Play/Pause Button
Stop Button
Next Button
Previous Button
Open/Close Button
SD Card Slot
USB Port
Disc Tray
Power Button
Front Panel Display
Remote Control Sensor
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
2 3 4 5 6 7 8 9
10 11
Page 10 Coby Electronics Corporation www.cobyusa.com Page 11 Page 10 Coby Electronics Corporation
1
2 4 3
5 6
Rear Panel
S-Video out
Composite Video Out
Composite Video Out ( Progressive Scan)
2.1-Channel Audio Out:
L-CH (Left Channel)
R-CH (Right Channel)
Coaxial Digital Audio Out
HDMI Port (High-Definition Multi-media
Interface)
1.
2.
3.
4.
5.
6.
