Cecilware CTR3.75 - Manual (Page 2)

2
Model
Number
CTR2.68LD CTR3.75
Dimensions
(WxDxH)
18"x18 3 / 8 " x 36½" 18¾"x18"x 33¼"
Inner Cabinet
Dimensions
14 7 / 16 "x 12 5 / 8 "x 25 3 / 8 " 16" x 14" x 29"
Capacity 2.68 cu. ft. 3.75 cu. ft.
Electrical 110V, 60 HZ, 1.8A 110V, 60 HZ, 2A
Input Power 92W 92W
Power
Consumption
1.0KW Hr/24Hrs. 1.2KW Hr/24Hrs.
Refrigerant
R134A - Thermoelectric
Cooling
R134A
Ship Weight 90 lbs. 85 lbs.
Setting and Temperature Adjustments
1. Adjust the storage temperature through the temperature controller.
2. The temperature adjustable capacity is from “1”-“5”. Adjust the storage temperature
by turning the temperature controller clockwise. The“5” setting is for colder storage
temperature. The knob can turn freely but can't turn clockwise from “5” to“1”.
Factory setting position is on “3” position.
3. Check if the knob is on the appropriate position before using. Frequent adjustments
is not appropriate when using.
4. Position “0” means refrigerator is off.
CTR2.68LD CTR3.75LD
