Hardware Installation
1. Turn Off the power to your computer.
2. Unplug the power cord and remove your computer’s cover.
3. Remove the slot bracket from an available PCIe slot.
4. To install the card, carefully align the card’s bus connector with
the selected PCIe slot on the motherboard. Push the board down
firmly.
5. Replace the slot bracket’s holding screw to secure the card.
6. Replace the computer cover and reconnect the power cord.
Driver Installation
For Windows® 2000/XP/Server 2003
1. Don’t insert the PCIe card into PCIe slot.
2. At the Windows desktop click Start, then Run.
3. Type D:\PCIe\MCS9901\XP\PCIeSetup32.exe, then click OK.
4. Press “Install” button to install the drivers.
5. Click “Exit” button to complete the driver installation.
6. Shutdown the PC.
7. Place the PCIe card into PCIe slot and then power on the system.
8. Once the system gets booted the Windows will automatically start
