Instruction Manual
AFH – Fast / FD
AFH/FD-BA-e-1110 4
3
rd Step:
Connect computer by standard RS 232 C and power plug cable
(included; 230V) to Junction Box. Doesn´t matter whether the
Computer is turned on or off.
4
th Step:
Insert Power Plug and make sure that the green Light
on the back side of the Junction box is on.
5
th Step:
Now first turn on
a) the Length Measurement Device
and after that
b) the
Force Gauge.
The software can be used now and force signal can be combined with length signal.
