For technical questions, please call 1-800-444-3353.
Item 45252
parts list and Diagram
pleaSe ReaD the FOllOWinG CaReFullY
THe mANuFACTuReR AND/oR DIsTRIbuToR HAs PRovIDeD THe PARTs lIsT AND Assembly DIAGRAm
IN THIS MANUAL AS A REFERENCE TOOL ONLy. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANy REPRESENTATION OR WARRANTy OF ANy KIND TO THE BUyER THAT HE OR SHE IS
qUALIFIED TO MAKE ANy REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS qUALIFIED TO REPLACE
ANy PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR ExPRESSLy
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN By CERTIFIED AND
LICENSED TECHNICIANS, AND NOT By THE BUyER. THE BUyER ASSUMES ALL RISK AND LIABILITy
ARIsING ouT oF HIs oR HeR RePAIRs To THe oRIGINAl PRoDuCT oR RePlACemeNT PARTs
THeReTo, oR ARIsING ouT oF HIs oR HeR INsTAllATIoN oF RePlACemeNT PARTs THeReTo.
parts list
part
Description
Qty
1
Gear box
1
2
Screw St5x48f
4
3
spring Washer Φ5
4
4
Washer Φ5
4
5
Friction bearing Φ19xφ32x23.8
1
6
Check Ring
1
7
o-Ring Φ8xφ1.5
1
8
Spindle
1
9
Impact Block
1
10
steel ball Φ5
23
11
Spring
1
12
steel ball Φ7.14
2
13
Gear shaft
1
14
Gear
1
15
Washer Φ8.1xφ16x3
1
16
Bracket
1
17
Sealing Ring
1
18
Gear box Cover
1
19
o-Ring Φ25.7xφ1.8
1
20
Felt Ring Φ9xφ18x4
1
21
Ball Bearing 6000.2Rs
1
22
Bearing Cover
1
23
Armature 120V
1
part
Description
Qty
24
Ball Bearing 608.2Z
1
25
Pin Φ8x40
1
26
Couple Gear
1
27
Needle Bearing\Hk081210
2
28
Washer Φ8xφ16x0.5
2
29
Baffle
1
30
Screw St4x55c
2
31
Stator 120V
1
32
Bearing Bush
1
33
Housing
1
34
Rating Label
1
35
Brush Holder Cap
2
36
Carbon Brush 120V
2
37
Brush Holder
2
38
Screw St4x18f
2
39
Handle Cover
1
40
Swtich
1
41
Screw St4x16c
2
42
Cord Clamp
1
43
Cord Sleeve
1
44
Cord 120V
1
45
Brand Label
1
