RENEWAL PARTS IDENTIFICATION
Motors
Capacitors
Manufacturer’s
Specifications
Manufacturer’s
Specifications
Part No.
Cat. No.
Volts Amps Phase Cycles RPM HP
Part No.
Cat. No.
Type Vac
Cap.
193-025776-001
HF2K007N
115
5.4
1
60
1625 1/3
040-025779-001
1270
Oil
370 5 MFD
193-025776-002
HF2K006N
230
2.54
1
60
1625 1/3
040-025779-002
1271
Oil
370 6 MFD
193-302120-011
P55YYBYV-887 460
0.9
3
60
1725 1/3
—
—
—
—
—
Voltages
Size
Part Number
V.A. Rating
Primary
Secondary
Large
315-052169-011
970
220, 230, 240, 440, 460, 480
110, 115, 120
315-052169-012
550, 575, 600
110, 115, 120
Small
315-304252-001
40
240 & 480
120
315-304252-003
575
120
Fuses — 600 Volt
Fuseholders
Manufacturer’s
Part Number
Amps
Cat. No.
Use
Part Number
Description
128-026510-003
30
JKS 30
Power
129-025643-002
600 Volt, 30 Amp, 3 Pole
128-026510-001
35
JKS 35
128-026510-004
40
JKS 40
Power
129-025643-001
600 Volt, 60 Amp, 3 Pole
128-026510-006
50
JKS 50
128-026510-007
60
JKS 60
128-027590-001
1
KTK-R-1
Control/
129-048473-001
2, 3, 4, 5 poles contact section
128-027590-008
8
KTK-R-8
Motor
129-048475-001
End barrier section for use
128-027590-010
15
KTK-R-15
with 129-048473-001
PARTS COMMON TO ALL HEATERS
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112-027568-001
Fan Delay . . . . . . . . . . . . . . . . . . . . . . . . . . 300-048038-001
Cutout . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300-049602-008
Manual Reset Cutout (Optional) . . . . . . . . . 300-117647-006
Grille . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134-119147-004
Louver Assembly . . . . . . . . . . . . . . . . . . . . 182-047073-009
Mounting Bracket - (Right Hand) . . . . . . . . 027-025836-001
(Left Hand) . . . . . . . . . 027-025836-002
Thermostat (Optional) . . . . . . . . . . . . . . . . 300-026604-001
Contactor . . . . . . . . . . . . . . . . . . . . . . . . . . 072-304551-008
Auxiliary Contact . . . . . . . . . . . . . . . . . . . . 072-304551-101
