Chicago Electric 40388 - Manual (Page 15)

Page 15- SKU: 40388
parts list
part code Q’ty description
1 CA10a1-60 1 SWITCH 115/30V
BA.B1.6 1 POWER CABLE
3 BA.B1.4 1 AMPERAGE CONTROL KNOB
4 BA.B1.7 1 GROUND CABLE
5 BA.B1.7 1 ELECTRODE CABLE
6 ND10 T90 1 GREEN PILOT LAMP
7 ND10 T90 1 YELLOW LAMP
8 GB8 18-85 3 SCREW M4 X 1
9 1 WELDING STEP SELECTOR
10 GB8 18-85 1 SCREW M.5 x 10
11 BA.B 1.4-1 1 LOCATING COLLAR
1 BA.B 1-5 1 BASE FRAME
13 BA.B1-6 4 FOOT
14 GB96-85 4 WASHER
15 GB18-85 4 SCREW M14 x 16
16 BA.B1-4 1 FRAME FOR MOVABLE IRON CORE
17 BA.B 1.3 MOVABLE IRON CORE
18 BA.B 1.3-1 INSULATION CUSHION
19 BA.B 1. 1 TRANSFORMER 40 x 60 ;OV
0 BA.B 1.-8 TRANSFORMER CARRIAGE
1 TJWT11E-140 1 THERMOSTAT
BA.B 1-7 1 BAFFLE
3 BA.B 04-7 1 CLEAR COVER
4 BA.B 1- 1 INDICATOR
5 BA.B 1-3 CLAMP RING
6 BA.B 1 .1 1 CASE
7 BA.B 1-1 1 HANDLE
8 GB8 45-85 1 SCREW ST3.9 x 5
9 1 RUBBER RING
pleASe reAd tHe FOllOWing cAreFully
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL
AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO
MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS
OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT
ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED
TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
REV 07i, 07k
