SKU 94882 PAGE 10
UNPACKING
When unpacking, check to make sure all parts shown on the Parts
Lists and Assembly Diagrams on pages 12-14 are included. If any parts
are missing or broken, please call Harbor Freight Tools at the number shown
on the cover of this manual as soon as possible.
ASSEMBLY INSTRUCTIONS
How to attach and adjust the Side Handle:
1. Slide the Clamp (122) over the Collet (8). Secure it using the Knob (120). ( See
Figure 1 below.)
2. To adjust the angle of the Side Handle, loosen the Knob (120). Adjust the angle
of the Side Handle, then tighten the Knob (120) to secure it.
122
Side Handle
120
8
Figure 1
