4-3
LANVIEW LEDs
The functions of the Token Ring Insertion LEDs are listed in Table 4-4.
The function of the Ring Speed LEDs are listed in Table 4-5.
Table 4-4. Token Ring Insertion LEDs
LED Color State
Green Inserted into ring
Off Not Inserted
Table 4-5. Ring Speed LEDs
LED Color State
Green 16 mbps
Off 4 mbps
