2
Printer Operation
46
Top Menu Sub Menu Default Menu Remarks
USB VCOM Protocol Auto Auto Selects the protocol (flow control) when
[VCOM Protocol] DTR operating USB VCOM.
X-ON
Machine Model Number – CL-S*** Displays the model name.
Information
Boot Version – *.* Displays the boot version.
[Machine Info]
ROM Version – ******** Displays the ROM version.
ROM Date – **/**/** Displays the date the ROM was prepared.
ROM CheckSum – **** Displays the check sum of the ROM.
Head Check – OK Displays the results of the head check.
NG
Print Counter – ****.*** km Displays the print counter.
Service Counter – ****.*** km Displays the service counter.
Sensor Monitor – *.* V Displays the sensor level.
Option Interface – None Displays the presence/absence of the
[Option I/F] LAN optional interface.
Test Mode Print Pattern Current Config Current Config Executes the test pattern.
Global Config
Sample
Head Check No Yes Executes head check.
No
Factory Default No Yes Initializes the set values of the configuration
No set to the state when the unit was shipped
from the factory.
Hex Dump No Yes Sets the hex dump mode.
No
Serial Monitor – – Displays the state of the serial interface.
Auto Calibration See Through See Through Executes the calibration of the sensor.
[Auto Cal] Reflect
Sensor Monitor See Through See Through Displays the level of the sensor.
Reflect
Global – Config Set 1 Config Set 1 Sets the Config Set.
configuration Config Set 2
[Global Config] Config Set 3
Mode Settings
[Datamax
® Emulation]
Note: To restore factory default settings, turn on printer power while pushing the MENU and PAUSE keys
simultaneously, then press the FEED key and the STOP key sequentially.
