4
Rear Panel
Aerial socket for connection to the supplied telescopic or other aerial
Headphone socket (3.5mm) for connection to headphones
Aux Speaker socket (3.5mm) for connection to the optional ST-1
speaker for full stereo output
Stereo Line Out socket (3.5mm) analogue output for connection to
an external amplifier or recorder
12V DC for connection to mains adapter
Quick start
This section provides information on how to set up and start using your EVOKE-1 Elgar. For further details on using your radio see Connecting to
other devices on page 5 and Using your EVOKE-1 Elgar on page 7.
1. Fully extend the telescopic aerial.
2. Attach the mains adapter and plug in to your power supply.
3. Push the Power button to switch the unit on. The LCD will light up and the display will show ‘PURE EVOKE-1’ and a progress bar on the
bottom line indicates the progress of an autotune to find the stations available in your area. If no stations are found you will be presented
with a series of options which you can use to retry the tuning process or adjust your aerial position, see Tuning for the first time on page 7.
The stations found will be stored in alphanumeric order and the first station on the list will be selected.
4. Adjust the Vol control if necessary to hear it.
5. Turn the Tune knob to see all the stations available and push to select and listen to another station.
