Compatible Systems 1220I - Manual (Page 3)

i
Chapter 1 - Introduction 1
A BOUT THE M ICRO R OUTER 1220 I 1
A N OTE A BOUT F IREWALLS 1
A N OTE A BOUT O N -D EMAND I NTERNETWORKING 1
M ICRO R OUTER 1220 I I NSTALLATION O VERVIEW 2
Chapter 2 - Getting Started 5
A F EW N OTES 5
Please Read The Manuals 5
Warranty and Service 5
Getting Help With the MicroRouter 1220i 5
W HAT Y OU W ILL N EED T O G ET S TARTED 6
Supplied with the MicroRouter 1220i 6
Needed For Installation 6
Ethernet Connection Requirements 6
10Base-T Twisted-Pair Ethernet 7
Telco Line Connection Requirements 7
V.35 Interface 7
RS-232 Interface 8
Chapter 3 - Network Installation 9
P LACING THE R OUTER 9
C ONNECTING THE R OUTER TO THE E THERNET 10
Connecting to Twisted-Pair Ethernet 10
C ONNECTING A L INE D EVICE TO THE M ICRO R OUTER 1220 I 10
Connecting Devices to the V.35 Interface 10
Connecting Devices to the RS-232C Interface 11
C ONNECTING AN O UT - OF -B AND M ANAGEMENT C ONSOLE 11
P OWERING U P THE R OUTER 12
