Clarion VRX756VD - Manual (Page 71)

English
Installation and Wire connection manual
280-8207-00
VRX756VD
73
9.
SAMPLE SYSTEMS
■ Sample System 1
VTR
Yellow
Yellow
Yellow
(TTX7501z
/TTX7504z)
(VCZ625)
(DCZ625)
(CC425E)
(VMA5894/
VMA7194)
VIDEO OUT
DVD A/C IN
TV IN
(WH100)
iPod VRX756VD
TV tuner
CeNET cable
(included the
TV tuner)
RCA video cable
(included the TV tuner)
Rear View
Monitor
RCA video cable (sold separately)
CeNet DVD Changer
CD Changer
CeNET Y-adapter
(CCA-519-601,
sold separately)
Ferrite clamp
(Included the DVD changer)
RCA video cab
le (included the VCZ625)
CeNET Cable
(included the Changer)
Front Speakers
Rear
Speakers
Set the [CeNET/STAND ALONE]
switch to the [CeNET] position.
CeNET cable
CCD Camera
Conector cable
(included the CC425E)
RCA cable
(sold separately)
VISUAL input
Wireless
Head phone
Red
White
Non fader output
(2-ZONE output)
RCA extension cable
(sold separately)
Connector cable
(CCA-649-600,
sold separately)
