Page 21
21
Model 1333SWE
Ref.
No.
Part No.
Description
Qty.
1
07386
Wash:.390 ID x 1.75 O.D.
1
2
684-0123A
Brkt Asm:Cvr:Belt
1
3
710-0191
Hex Hd. Screw 3/8-24 x 1.25 (Gr. 8)
2
4
710-0237
Hex Hd. Screw 5/16-4 x .625 (Gr.5)
3
5
710-0502A
Hex TT-Sems Screw 3/8-16 x 1.25
4
6
710-0607
Hex TT-Tap Screw 5/16-18 Thd.
3
7
710-1245
Hex Lock Screw 5/16-24 x .875
1
8
712-0116
Jam Nut 3/8-24 Thd.
1
9
714-0118
Key
1
10
731-0321
Cvr:Belt
1
11
732-0303
Spring:Extension
1
12
736-0217
L-Wash .3/8
2
13
736-0242
Bell-wash. .340 I.D. x .872 O.D.
4
14
736-0264
Washer:Flat
3
16
738-0215A
Shoulder Screw
1
17
748-0234
Shoulder Spacer
1
18
754-0131
V-Belt
1
19
756-0240
Idler:Flat
1
20
756-0241B
Double Pulley
1
21
784-5726
Idler:Brkt
1
22
712-0324
Hex Lock Nut 1/4-20 Thd.
1
23
732-0705
Cable Control Wire
1
24
736-0173
Fl-Wash. .28 x .74 x .063
1
Ref.
No.
Part No.
Description
Qty.
IMPORTANT: For a proper working machine use Factory Approved Parts.
V-BELTS are specially designed to engage and disengage safely. A substitute (non OEM) V-Belt can be dangerous by not
disengaging completely.
Label No.
Description
777D03024
Handle Panel Cub Cadet Power Steering
777D03039
Cub Cadet 1333SWE Top of Auger
777D03031
13 Hp OHV Side of Engine
777S30004
Top of Chute Danger/Warning
777S30005
Top of Auger Danger/Warning
777I20751
Control Panel Chute Tilt Control
777I20420
Control Panel Traction Control
