SAVE THESE INSTRUCTIONS
Page 8
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011
English
When ordering parts, be sure to quote the model number and part numbers.
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
PP
AA
RR
TT
SS
RR
EE
FF
EE
RR
EE
NN
CC
EE
REF. NO.
DESCRIPTION
QTY.
SPARE PART
NO.
1
PRESSURE GAUGE
1
11411
2
6-WAY VALVE
1
11378
3
DRAIN OUTLET COVER
1
11131
4
CLAMP
1
11380
5
TANK O-RING
1
11379
6
SAND SHIELD
1
11382
7
CENTER PIPE HUB
1
11383
8
LATERAL
10
11384
9
DRAIN VALVE CAP
1
11456
10
DRAIN VALVE O-RING
1
11385
11
L-SHAPE O-RING
4
11228
12
HOSE WITH NUTS
2
11009
13
SAND FILTER INTERCONNECTING HOSE
1
11388
14
LEAF TRAP NUT
1
11479
15
LEAF TRAP O-RING
1
11232
16
BASKET
1
11260
17
FILTER HOUSING NUT
1
11261
18
L-SHAPE O-RING
1
11412
19
SEDIMENT RELEASE VALVE
1
10460
20
VALVE O-RING
1
10264
21
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
2
10747
22
HOSE O-RING
2
10262
23
STEP WASHER
2
10745
24
STRAINER NUT
2
10256
25
FLAT STRAINER RUBBER WASHER
2
10255
26
THREADED STRAINER CONNECTOR
2
11235
27
ADJUSTABLE POOL INLET NOZZLE
1
11074
28
ADAPTOR B
2
10722
29
STRAINER CONNECTOR
2
11070
30
POOL INLET NOZZLE
1
11071
31
STRAINER GRID
1
11072
32
SCREW
2
11381
33
PUMP MOTOR & CONTROL
1
11387EG
34
PRE-FILTER ASSEMBLY
1
11371
35
LEAF TRAP COVER
1
11480
36
SAND FILTER PUMP MOTOR INLET O-RING
2
11457
37
14” SAND FILTER PUMP AND COMBO TANK
1
11498
38
14” SAND FILTER PUMP TANK BASE
1
11513
