Classe Audio CT-10 - Manual (Page 39)

37
SPECIFICATIONS:
FM
Tuning range FM 100 KHz Steps
87.5 MHz to 108 MHz
30 dB quieting – Mono 2 uV
30 dB quieting – Stereo 4 uV
Output level 2 Kohm load 780 mV
50 dB quieting sensitivity – Mono 4 mV
50 dB quieting sensitivity – Stereo 40 mV
Distortion Input: 1mV 1KHz 0.15%
Frequency response 10 Hz to 15 kHz
Separation 100 Hz 55.0 dB
AM
Tuning range AM 10 kHz steps
520 kHz to 1720 kHz
Intermediate frequency 450 kHz
Quieting sensitivity at S/N 20 dB 603 kHz 450 uV
Quieting sensitivity at S/N 20 dB 1404 kHz 450 uV
AM suppression input: 1 mV AM 30% 70 dB
Signal to noise 999KHz 47 dB
Distortion 0.8%
Output level 2 KOhm load at 5 mV/M input 180 mV
Dimensions
Net
19” W x 4 5 /
16
” H x 16 1 /
2
D
48.2 X 11 X 42 cm
Gross 24.5” W x 19.5” D x 9.5” H
62.2 x 49.5 x 24.3 cm
Weight
Net
16 lbs. 7.28 kg
Gross 24 lbs. 10.91 kg
CLASSÉ AUDIO LTD. RESERVES THE RIGHT TO CHANGE OR MODIFY THESE SPECIFICATIONS
WITHOUT NOTICE.
