6
Troubleshooting
The LED indicator is not
illuminated. Check fuse in amplifier.
Verify connections are correct.
Short cut. Verify that there are no short
cut.
Grounding is wrong. Verify for proper grounding.
No signal input. Check if the audio cable is
connected.
No sound
The volume is minimum. Adjust the volume level.
There is no power to REM
jack when the radio is on. Check connections to radio. The amplifier can not be
switched on
The fuse has blown. Verify and replace blown fuse.
Abnormal distorted sound Input control level is too high. Adjust input LEVEL control.
Specification
Output power 160 W (Peak), 80 W (Nominal)
THD <0.4%
Input level 110 mV (RCA-Line-In), 0.5 V (Speaker input)
Power source DC 10 V - 14,4 V Negative ground
Frequency response Input: 35 150 Hz
Bass Boost 0 - 12 dB @ 45 Hz
LPF Filter 50 - 150 Hz
Sub Sonic Filter 20 - 50 Hz
Phase 0º/180º
Dimensions 347 250 70 mm
Weight 4.51 kg
