Matrix of user-selectable features
Feature Select
Column 1
1st latched
Column 2
2nd latched
Column 3
3rd latched
Column 4
4th latched
Column 5
5th latched
Row 1
1st momentary
Sound 1:
on
/off
info on page 17
Add new remote to channel 1
info on page 8–9
NOTE 1
Test/adjust primary (normal) zone
of the Magnetic Resonance Sensor
info on page 13
NOTE 6
QuietChirps: on/
off
info on page 18
NOT USED
Row 2
2nd momentary
Sound 2:
on
/off
info on page 17
Add new remote to channel 2
info on page 8–9
NOTE 2
Test/adjust secondary (high) zone
of the Magnetic Resonance Sensor
info on page 13
NOTE 7
Long-term
chirp silencing: on/
off
info on page 17
Channel 4 timer:
1sec–2.5min (
30sec
)
NOTE 9
Row 3
3rd momentary
Sound 3:
on
/off
info on page 17
Add new remote to channel 3
info on page 8–9
NOTE 3
Pulsed
/constant
ground output upon panic
15-second entry delay: on/
off
info on page 13
Channel 4 output:
pulsed,
timed or latched
Row 4
4th momentary
Sound 4:
on
/off
info on page 17
Add new remote to channel 4
info on page 8–9
NOTE 4
FACT
: on
/off
info on page 15
AutoLock/UnLock:
on
/off
info on page 18
Siren duration:
30
/60 seconds
info on page 18
Row 5
5th momentary
Sound 5:
on
/off
info on page 17
Erase all channels
info on page 8–
9 NOTE 5
Factory-delayed
courtesy lights: on/
off
Enhanced AutoArming: on
/off
info on page 13
NOT USED
Row 6
6th momentary
Sound 6:
on
/off
info on page 17
NOT USED
Set a new secret valet code
info on page 12
NOTE 8
AutoArm & Lock: on/
off
info on page 13
NOT USED
Gray cells indicate features that require programming by trained Clifford installers. DO NO
T change any of these settings.
✱
WARNING:
If you have remote window and sunroof closure, DO NOT CHANGE THIS SETTING: it requires insta
ller-only adjustment. Changing the duration may cause damage.
NOTE 1:
Transmit channel 1 (or other channel of your choosing) of the new remote
control. You will hear two chirps to indicate that the code has been accepted and recorded. NOTE 2:
Transmit channel 2 (or other channel of your choosing) of the new remote
control. You will hear two chirps to indicate that the code has been accepted and recorded. NOTE 3:
Transmit channel 3 (or other channel of your choosing) of the new remote
control. You will hear two chirps to indicate that the code has been accepted and recorded. NOTE 4:
Transmit channel 4 (or other channel of your choosing) of the new remote
control. You will hear two chirps to indicate that the code has been accepted and recorded. NOTE 5:
When you hear the two chirps, all remote control codes will have been erased
from system memory. You must now add the new and/or existing remote controls to the system (i.e., program channels 1–5 of each remote that will be used with your IntelliGuard 700 system). NOTE 6:
Turn off the ignition and exit the vehicle. Firmly “thump” the window pillar
with the side of your fist. You should hear a chirp to confirm activation of the sensor’s
main zone. Use remote control button 2 to increase sensitivity, button 4 to decrease it. Higher and higher pitched tones confirm each sensitivity increase, lower and lower tones confirm each decrease. Repeat until the sensor is set to the sensitivity you wish, then press button 1 to record the new sensitivity level and exit sensor test/adjust mode (you’ll hear 3 chirps to confirm this). You may now either arm the system with channel 1 or enter the vehicle. NOTE 7:
Use the same procedure as NOTE 7, but strike the window pillar lightly.
NOTE 8:
Immediately flip the switch to its latched position
, then enter the new code
that you wish to use. Make sure to return the switch to its center position when complete, then wait 3 seconds (you will hear two chirps when the system has accepted the new code). Turn the ignition off.
VERY IMPORTANT:
You must immediately
test your new secret disarming/valet code
: Turn the ignition on, enter your new code,
then flip the switch to its latched position. The LED will illuminate. If it does not, the new code you programmed and the one you just entered do not match.
The system has
reverted to the previous code. NOTE 9:
The timer starts as soon as you enable this feature. When the duration you
wish has been reached, press button 1 on the remote control. You will hear two chirps to confirm the new duration.
✱
