CDA PC85SC User Manual

Page 7

Installing Bottom Trim

Open the door of refrigerator compartment and take out the bottom trim.
Fasten it to the bottom of refrigerator with screws as illustrated.

Wear a pair of gloves to protect your hands when
removing or installing the bottom trim and adjustable
legs of the refrigerator.

Installation of legs requires the joint efforts of at least two adults. Don’t

attempt to handle it by yourself. Make sure the appliance is not tilted too

much so that it overbalances.Before moving a refrigerator, the adjustable

legs

should be removed to prevent floor damage.

NOTE

Installing front cover of delicatessen drawer

Open the door of refrigerator compartment. Take out the front cover of
delicatessen drawer from the crisper cover. Then place the rotary shaft at both
ends of the drawer into the supporting slot of the slide guide, and turn the
front cover of delicatessen drawer down.

Preparation

Installing Legs

Take out the accessory bag containing the legs from the refrigerator

compartment. The appliance should be tilted.by one person and the

legs should be installed as illustrated

by the other person.

NOTE

Leg

Reserved

hole

Removing & Replacing Door Handle

Take out the door handles from the refrigerator compartment (2 longer handles
to be installed on the refrigerator and 1 shorter handle to be installed on the
freezer). The following instructions should be observed.
Removing & Replacing Refrigerator Door Handle
Get 2 fasteners out of the accessory bag and place them in 2 reserved holes in
the left door. Install a handle by attaching the reinforcing plate to the fasteners
and then pushing the handle to the left into its place. Install the right handle
in the same way. To remove the handle, push it to the right.

Fastener

Reinforcing

plate
