Grill Assembly

continued

11.

Push down on grate to lock into tabs on right side of grill.
(Fig. 11)

12.

Insert remaining grill grate under tab at back of grill, then push
down on grate to lock into tabs on left side of grill. (Fig. 12)

13.

Place warming rack on tabs at left side of grill and push down to
lock. (Fig. 13)

14.

Press down on other side to lock warming rack into tabs on right
side of grill. (Fig. 14)

15.

Turn both control knobs on front of grill to OFF position. (Fig. 15)

Fig. 12

Fig. 13

Fig. 14

Fig. 15

Fig. 11
